Description\MODEL |
Unit |
AC-5160 |
AC-5180 |
AC-51120 |
AC-51160 |
AC-51200 |
AC-51240 |
||||
|
CAPACITY |
|
|
|||||||||
|
Center height |
mm |
680 |
|||||||||
|
Swing over bed |
mm |
1300 |
|||||||||
|
Swing over cross slide |
mm |
900 |
|||||||||
|
Dist. between center |
mm |
1700 |
2200 |
3200 |
4200 |
5200 |
6200 |
||||
|
Width of bed |
|
770 |
|||||||||
|
SPINDLE |
|
|
|||||||||
|
Spindle bore |
mm |
Ø155(6") |
Ø230(9")opt. |
Ø305(12")(opt.) |
Ø 410(16")(opt.) |
Large spindle bores are available on request |
|||||
|
Spindle nose |
- |
A2-11 |
A2-15 |
A2-20 |
A2-28 |
||||||
|
Spindle speeds |
rpm |
H: 151~800 M: 31~150 L: 6~30 |
H: 111~560 M: 21~110 L: 4~20 |
H: 54~270 M: 11~53 L: 2~10 |
H: 43~215 M: 9~42 L: 1.5~8 |
||||||
|
TRAVEL |
|
|
|||||||||
|
Cross slide travel X-axis |
mm |
680 |
|||||||||
|
Longitudinal travel Z-axis |
mm |
1500 |
2000 |
3000 |
4000 |
5000 |
6000 |
||||
|
Ball screw ( Dia. x pitch) |
mm |
X: Φ40 x P8 Z: Φ80 x P16 |
|||||||||
|
FEED RATE |
|
|
|||||||||
|
X-axis rapid travel |
m/min |
5 |
|||||||||
|
Z-axis rapid travel |
m/min |
6 |
5 |
4 |
|||||||
|
TAILSTOCK |
|
|
|||||||||
|
Quill dia. |
mm |
Ø165 |
|||||||||
|
Quill travel |
mm |
300 |
|||||||||
|
Quill inside taper |
|
MT#6 |
|||||||||
|
MOTOR |
|
|
|||||||||
|
Servo motor |
kw |
22 / 33 、 28 / 42 (opt.) |
|||||||||
|
X-axis drive motor |
Nm |
23.5 |
|||||||||
|
Z-axis drive motor |
Nm |
32 |
|||||||||
|
Coolant pump motor |
Bar |
6.2 (50HZ) / 8.3 (60HZ) |
|||||||||
|
WEIGHT |
|
|
|||||||||
|
Net weight |
kg |
12000 |
12800 |
14400 |
16000 |
17600 |
19200 |
||||
Note:
We have the right to modify the specification or designs. If there are subjected to change without
prior notice.
AC-5100 Series
ACCESSORIES
|
STANDARD ACCESSORIES |
|
OPTIONAL ACCESSORIES |
|
l Fagor control |
l Fanuc & Siemens Control on request |
|
|
l Main spindle 2 steps speed auto Change by |
l 3-Jaw manual chuck |
|
|
l CNC Control |
l 4-Jaw manual chuck |
|
|
l Coolant equipment |
l 3-Jaw hydraulic chuck |
|
|
l Lubricate equipment |
l Manual toolpost (4T) |
|
|
l Work light |
l Electric servo toolpost (H4) |
|
|
l Center sleeve |
l Electric turret (V8) |
|
|
l Dead center |
l Hydraulic turret (V8) |
|
|
l Tool box & tools |
l C axis (Living tool) |
|
|
l Operation & Service Manual |
l Steady rest |
|
|
|
l Follow rest |
|
|
|
l Boring attachment |
|
|
|
l Double chuck system |
|
|
|
l Rotating center |
|
|
|
l Hydraulic tailstock |
|
|
|
l Rotating tailstock |
|
|
|
l Chip conveyer |
|
|
|
l Heat exchanger |
|
|
|
l Spindle oil cooler |
|
|
|
|
l Tailstock type : Build in type quill |
